Bose Acoustimass 10 Series II cracked open

Photos of the┬áBose Acoustimass 10 Series II cracked open, as well as a few transparent plexiglass showcase edition. See what’s inside this mighty subwoofer, packing three small woofer speakers, in a weird bandpass arrangement explained in one of the pictures.

  • Tim Koers

    How do I remove the front panel (the plastic part where the sound comes trough)?
    I have a bad center woofer, which is located in a room that is far away from handreach.

    Thanks,
    Tim

    • Tech

      I guess the only option would be to try pry it open with a wide flat blade, as there are no screws..
